Edible Oil Safety Detector

Introduction:

The edible oil safety detector is an integrated rapid detection and analysis equipment for oil products, which can quickly detect the content of aflatoxin, benzo [a] pyrene, capsaicin, etc. in edible vegetable oil, edible lard, peanut oil, sunflower oil, rice bran oil, food, meat products, etc; Through testing, it can be determined whether vegetable oil meets national standards or whether it is inferior oil, gutter oil, etc.

Instrument Application:

Widely used in quality supervision and inspection, business management, fried food production bases, food and drug supervision bureaus, health departments, meat product processing enterprises, shopping malls and supermarkets, major food safety monitoring systems and other units.

Testing items: aflatoxin, benzo [a] pyrene, capsaicin, etc

Technical Parameters:

1. Android operating system, 7-inch LCD touch screen display, efficient UI interactive interface, user-friendly operation experience.

2. High degree of intelligence, with self check and zero adjustment functions upon startup, and automatic detection of repeatability.

4. Integrated portable rapid inspection equipment, meeting the needs of on-site and mobile testing.

5. The principle of colloidal gold detection, track based automatic transmission scanning, CT line automatic recognition, and automatic display of CT coordinate curve upon completion of detection.

6. Equipped with a built-in camera for taking photos, it can display real-time images of the gold tag card and automatically exit the detection card after completion.

7. The light source adopts imported ultra high brightness light-emitting diodes, which have high precision, strong stability, controllable light source, can turn off unused light sources, and lower power consumption.

8. Configure USB interface, support USB flash drive transfer, no need for driver insertion and removal, convenient for data transfer to the computer.

9. It has an editable menu library for multiple types of samples, allowing for flexible selection of detection samples. Different detection channels can simultaneously detect different sample items.

10. High sensitivity, high detection accuracy, high repeatability accuracy, scanning high-precision optical sensor.

11. Equipped with a cloud platform, the instrument has WiFi networking upload function to quickly upload data for long-term data management.

12. The built-in operation demonstration video of the instrument is your laboratory guidance expert by your side.

13. Embedded thermal printer, the detection report can be printed manually or automatically.

14. Compatible with all colloidal gold cards on the market, with unrestricted use of consumables, greatly enhancing the user experience.

15. Sample numbers are automatically accumulated.

16. The testing items can be expanded.

17. The test results can be printed and uploaded in batches.

18. Configurable large capacity lithium battery, firmware upgradable.

Main Parameters:

1. The main control chip adopts ARM Cortex-A7, RK3288/4-core processor, with a main frequency of 1.88GHz, fast operating speed, and strong stability.

2. Display mode: 7-inch LCD touch screen display, user-friendly Chinese operation interface, intuitive and simple reading.

3. Dual use of AC and DC, powered by 12V DC, can be connected to a car power supply, and can be equipped with a 6-hour high-capacity rechargeable lithium battery for easy flow testing.

6. Built in new national limited edition standards, on-site comparison with measured results, and continuous updating of standards.

9. The testing items can be expanded.

10. The test results can be printed and uploaded in batches.

11. The test results are in an Excel spreadsheet, which can be copied by connecting to a computer.

12. The storage capacity for test results is 200000 records

13. Supports USB storage, standard USB interface, and driver free installation.

14. The firmware can be upgraded.

15. Instrument size: 43 × 35 × 20cm, net weight of host: 5.2kg
